Allis Chalmers 540
| Production |
| Manufacturer | Allis Chalmers
|
| Wheel Loader |
| Allis Chalmers 540 Power |
| Engine (net) | 59.5 hp
44.4 kW
|
| Mechanical |
| Four-wheel drive |
| Articulated power steering |
| Four-post ROPS/FOPS. Cab optional with heater. |
| Photos |
| No photos of the Allis Chalmers 540 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Pressure | 2250 psi
155.1 bar
|
| Pump flow | 17 gpm
64.3 lpm
|
| Tractor hitch |
| Rear Type | I OptOptional
|
| Rear lift (at ends) | 675 lbs
306 kg
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 42
|
| Battery volts | 12
|
| Battery AH | 53
|
| References |
 |
| 540 Wheel Loader published in 1980, by Allis Chalmers |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on May 20, 2025 |
