Allis Chalmers 710C
|
|
| Production | |
| Manufacturer | Allis Chalmers |
| Industrial tractor | |
| Allis Chalmers 710C Engine | |
| Allis-Chalmers 3.3L 4-cyl diesel | |
 Engine details ... |
| Allis Chalmers 710C Transmission | |
| 4-speed torque converter | |
 Transmission details ... |
| Allis Chalmers 710C Power | |
| Engine | 65 hp 48.5 kW |
| PTO (claimed) | 25 hp 18.6 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | inboard planetary |
| Power steering | |
| Mechanical wet disc brakes | |
| Four-post ROPS/FOPS. | |
| Photos | |
| No photos of the Allis Chalmers 710C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 20 gal 75.7 L |
| Hydraulic system | 27 gal 102.2 L |
| Hydraulics | |
| Type | open center |
| Capacity | 27 gal 102.2 L |
| Rear valves | 2 |
| Pump flow | 18 gpm (loader) 68.1 lpm |
| 11 gpm (aux) 41.6 lpm | |
| Total flow | 29 gpm 109.8 lpm |
| Steering flow | 5 gpm 18.9 lpm |
| Steering press. | 1500 psi 103.4 bar |
| Tractor hitch | |
| Rear Type | II |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2100 |
| Dimensions & Tires | |
| Wheelbase | 84 inches 213 cm |
| Front tire | 11L-16 |
| Rear tire | 16.9-24 |
 Full dimensions and tires ... | |
| Allis Chalmers 710C attachments | |
| front-end loader | |
 Attachment details ... |
| 710C Serial Numbers | |
| Location: | Serial number plate on the left side of the 710C, just behind the engine. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 42 |
| 61 OptOptional | |
| Batteries | 1 |
| 2 OptOptional | |
| Battery CCA | 95 |
| Battery volts | 12 |
| Battery Group | 30H |
| References | |
 | |
| Operator's Manual 710C / 714C / 715C published in 1982, by Allis Chalmers |
