Ford 4000
|
|
| Production | |
| Manufacturer | Ford |
| Industrial tractor | |
| Ford 4000 Engines | |
| Ford 2.8L 4-cyl gasoline | |
| Ford 2.8L 4-cyl diesel | |
| Fuel tank | 17 gal 64.3 L |
 Engine details ... | |
| Ford 4000 Transmissions | |
| 4-speed gear | |
| 12-speed | |
| 4-speed mechanical shuttle | |
| 10-speed full power shift | |
 Transmission details ... |
| Ford 4000 Power | |
| Engine (gross) | 62.5 hp 46.6 kW |
| Mechanical | |
| Two-wheel drive | |
| Power steering | |
| Open operator station. |
| Photos | |
| No photos of the Ford 4000 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2000 psi 137.9 bar |
| Pump flow | 4 gpm 15.1 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift | 2360 lbs 1070 kg |
| Power Take-off (PTO) | |
| Rear PTO | transmission |
| independent *Indepndent PTO available with Select-o-Speed transmission. | |
| Rear PTO Type | 540 (1.375) |
| 540/1000 (1.375) | |
| Engine RPM | 540@1485 (gear) |
| 540@1750 (SoS) | |
| Dimensions & Tires | |
| Wheelbase | 79 inches 200 cm |
| Weight | 3084 lbs 1398 kg |
| Front tire | 7.50-16 |
| Rear tire | 13.6-28 |
 Full dimensions and tires ... | |
| Ford 4000 attachments | |
| blade | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| 4000 Serial Number Location | |
 | |
| Serial number stamped into the starter mount casting. |
| 4000 Serial Numbers | |
| 1962 | 1001 |
| 1963 | 11948 |
| 1964 | 38931 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Charging system | generator |
| Gas Battery volts | 6 |
| Diesel Battery volts | 12 |
| References | |
 | |
| Industrial Tractors and Equipment published in 1964, by Ford | |
| Ford for Snow Removal published in 1964 |
