John Deere 210LJ



John Deere 210LJ industrial tractor photo
2008 - 2011
Industrial tractor
Series:210LJ
210K EP ↓
Production
ManufacturerJohn Deere
TypeIndustrial tractor
John Deere 210LJ Engine
John Deere 4.5L 4-cyl diesel
Engine details ...
John Deere 210LJ Transmission
4-speed full power shift
Transmission details ...
John Deere 210LJ Power
Engine84 hp
62.6 kW
PTO (claimed)55 hp
41.0 kW
Mechanical
Chassis4x4 MFWD 4WD
Final drivesoutboard planetary
Brakeshydraulic wet disc
CabTwo-post canopy ROPS/FOPS. Cab optional.
Photos
No photos of the John Deere 210LJ are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel27 gal
102.2 L
Hydraulic system16.3 gal
61.7 L
 20 gal (with PTO)
75.7 L
Hydraulics
Typeopen center
Capacity16.3 gal
61.7 L
 20 gal (with PTO)
75.7 L
Pressure2750 psi
189.6 bar
Valves4 to 5
Total flow25.3 gpm
95.8 lpm
Tractor hitch
Rear TypeII OptOptional
Power Take-off (PTO)
Rear PTOcontinuous OptOptional
Rear RPM540
Dimensions & Tires
Weight14510 lbs
6581 kg
Front tire12-16.5
Rear tire16.9-24
Full dimensions and tires ...
John Deere 210LJ attachments
front-end loader
Attachment details ...
Electrical
Charging systemalternator
ROPS Charging amps70
Cab Charging amps90
Batteries1
 2 (optional)
Battery volts12
References
210LJ reference literature
LJ Loaders published in 2008, by John Deere
