John Deere 210LE
|
|
| Production | |
| Manufacturer | John Deere |
| Industrial tractor | |
| John Deere 210LE Engines | |
| John Deere 4.5L 4-cyl diesel | |
| John Deere 4.5L 4-cyl | |
 Engine details ... |
| John Deere 210LE Transmissions | |
| 4-speed power shuttle | |
| 4-speed full power shift | |
 Transmission details ... |
| John Deere 210LE Power | |
| Engine (gross) | 84.5 hp 63.0 kW |
| Engine (net) | 80 hp 59.7 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Power steering | |
| Hydraulic wet disc brakes | |
| Two-post ROPS/FOPS. Cab optional. | |
| Photos | |
| No photos of the John Deere 210LE are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 26 gal 98.4 L |
| Hydraulic system | 14.4 gal 54.5 L |
| Front axle | 9.2 qts 8.7 L |
| Rear axle | 14 qts 13.2 L |
| Hydraulics | |
| Type | open center |
| Capacity | 14.4 gal 54.5 L |
| Pressure | 2750 psi 189.6 bar |
| Pump flow | 25 gpm 94.6 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift (at ends) | 6870 lbs 3116 kg |
| Rear lift (at 24"/610mm) | 3790 lbs 1719 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent OptOptional |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 83.3 inches 211 cm |
| Weight | 9130 lbs 4141 kg |
| Front tire | 12-16.5 |
| Rear tire | 16.9-24 |
 Full dimensions and tires ... | |
| John Deere 210LE attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 65 |
| Batteries | 1 |
| 2 OptOptional | |
| Battery CCA | 925 |
| Battery volts | 12 |
| References | |
 | |
| LE Loaders published in 2008, by John Deere |
