McCormick Intl X6.616
| | 2023 - |
| X6.6 Series | | Utility tractor |
|
Series map:
X6.616
X6.618
155.0hp
166.0hp
| Production |
| Manufacturer | McCormick Intl (a part of Argo)
|
| Utility tractor |
| McCormick Intl X6.616 Power |
| Engine (gross) | 155 hp
115.6 kW
|
| Engine (max) | 165 hp
123.0 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Trailer brakes | pneumatic OptOptional
|
| Cab standard with air-conditioning. |
| Photos |
| No photos of the McCormick Intl X6.616 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | closed-center load-sensing
|
| Rear valves | 3 to 5
|
| Pump flow | 29.1 gpm
110.1 lpm
|
| SCV flow | 21.1 gpm
79.9 lpm
|
| Steering flow | 10 gpm
37.9 lpm
|
| Tractor hitch |
| Rear Type | III
|
| Control | position and draft control
|
| Rear lift | 18519 lbs
8400 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Battery volts | 12
|
| References |
 |
| X6.6 published in 2023, by McCormick |
