McCormick Intl X7.617
|
|
| Production | |
| Manufacturer | McCormick Intl (a part of Argo) |
| Row-Crop tractor | |
| McCormick Intl X7.617 Engine | |
| FPT 6.7L 6-cyl diesel | |
| Fuel tank | 74 gal 280.1 L |
| Exhaust fluid (DEF) | 12.15 gal 46.0 L |
 Engine details ... | |
| McCormick Intl X7.617 Transmission | |
| 30-speed six-speed power shift | |
 Transmission details ... |
| McCormick Intl X7.617 Power | |
| Engine (gross) | 151 hp 112.6 kW |
| Engine (max) | 155 hp 115.6 kW |
| Engine (boost) | 165 hp 123.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | pneumatic OptOptional |
| hydraulic OptOptional | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the McCormick Intl X7.617 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed-center load-sensing |
| Mid valves | 2 OptOptional |
| Front valves | 2 to 5 |
| Pump flow | 32.5 gpm 123.0 lpm |
| 42.3 gpmOptOptional 160.1 lpm | |
| SCV flow | 21.1 gpm 79.9 lpm |
| Steering flow | 13.7 gpm 51.9 lpm |
| Tractor hitch | |
| Rear Type | III |
| Control | position and draft control |
| Rear lift | 14110 lbs 6400 kg |
| 20503 lbsOptOptional 9300 kg | |
| Front Hitch | IIIN OptOptional |
| Front lift | 7717 lbs 3500 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540 (1.375) |
| 1000 (1.375)OptOptional | |
| Engine RPM | 540@2005 |
| 540E@1608 | |
| 1000@1995 | |
| 1000E@1600 | |
| Front PTO | independent OptOptional |
| Clutch | electro-hydraulic |
| Front PTO Type | 540 (1.375) |
| Engine RPM | 1000@1920 |
| Dimensions & Tires | |
| Wheelbase | 108.7 inches 276 cm |
| Weight | 14771 lbs 6700 kg |
| Front tire | 600/60R28 |
| Rear tire | 710/60R38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| X7 SWB published in 2023, by McCormick |
