CaseIH Farmall 120C
| | 2015 - 2027 |
|
| Farmall C Series | | Utility tractor |
|
Series map:
Farmall 110C
Farmall 120C
102.2hp*
110.0hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | CaseIH (a part of CNH)
|
| Utility tractor |
| CaseIH Farmall 120C Power |
| Engine (max) | 115 hp
85.8 kW
|
| PTO (claimed) | 99 hp
73.8 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | electro-hydraulic
|
| Hydraulic wet disc brakes |
| Cab standard with air-conditioning. |
| Photos |
| No photos of the CaseIH Farmall 120C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Rear valves | 2 or 3
|
| Pump flow | 21.7 gpm
82.1 lpm
|
| Steering flow | 9.7 gpm
36.7 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | position and draft control
|
| Rear lift (at 24"/610mm) | 4123 lbs
1870 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic wet disc
|
| Rear PTO Type | 540/1000
|
| Engine RPM | 540@1935
|
| | 540E@1535
|
| | 1000@1926
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Battery volts | 12
|
| References |
 |
| Farmall C published in 2025, by CaseIH |
| Farmall Utility C Specifications published in 2025, by CaseIH |
| Page information |
 |
| Copyright 2026 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on March 15, 2026 |
©2000-2026 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Transmission details ...
Full dimensions and tires ...
Attachment details ...
