Tractors > John Deere > 9RX 710

John Deere 9RX 710



John Deere 9RX 710 tractor photo
2025 -
9R Series
Articulated Crawler tractor
Series map:
9RX 640
9RX 710
9RX 770
631.6hp
710.0hp
770.0hp
Production
ManufacturerJohn Deere
Articulated Crawler tractor
Built in Waterloo, Iowa, USA
Original price was $1,125,427 in 2026
John Deere 9RX 710 Engine
John Deere 18.0L 6-cyl diesel
Fuel tank515.7 gal
1951.9 L
Engine details ...
John Deere 9RX 710 Transmission
21-speed full power shift
Transmission details ...
John Deere 9RX 710 Power
Engine (gross)710 hp
529.4 kW
Engine (net)682 hp
508.6 kW
Engine (max)781 hp
582.4 kW
PTO (claimed)335 hp
249.8 kW
Mechanical
Drivearticulated-crawler
Final drivesoutboard planetary
Differential lockelectro-hydraulic front and rear
Articulated power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
Cab standard with air-conditioning.
Photos
No photos of the John Deere 9RX 710 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed-center PFC
Pressure2900 psi
200.0 bar
Valves4 to 8
Pump flow56 gpm
212.0 lpm
 112 gpm*Dual pumps
423.9 lpm
 168 gpm*Triple pumps
635.9 lpm
SCV flow35 gpm
132.5 lpm
 45 gpm*With high-flow ¾ inch coupler
170.3 lpm
Tractor hitch
DrawbarCat. 5
Power Take-off (PTO)
Rear PTOindependent OptOptional
Rear PTO Type1000 (1.75)
Engine RPM1000@1812
Dimensions & Tracks
Wheelbase181.9 inches
462 cm
Weight74000 lbs
33566 kg
30-inch tracks
Full dimensions and tracks ...
Electrical
Charging systemalternator
Charging amps330
Batteries5
Battery CCA950
Battery volts12
Battery Group31
References
9RX 710 references literature
9RX 710, 9RX 770, 9RX 830 Tractors published in 2025, by John Deere
