Tractors > CaseIH > Magnum 355 Rowtrac

CaseIH Magnum 355 Rowtrac



CaseIH Magnum 355 Rowtrac tractor photo
2025 -
Magnum Series
Half-track Crawler tractor
Series map:
Magnum 355 Rowtrac
Magnum 385 Rowtrac
355.0hp
385.0hp
Production
ManufacturerCaseIH (a part of CNH)
Half-track Crawler tractor
Built in Racine, Wisconsin, USA
Original price$638 (604 2026 Power Shift )
$638,604 (2026 CVT )
CaseIH Magnum 355 Rowtrac Engine
FPT 8.7L 6-cyl diesel
Fuel tank163 gal
617.0 L
Exhaust fluid (DEF)26 gal
98.4 L
Engine details ...
CaseIH Magnum 355 Rowtrac Transmission
continuously-variable transmission
Transmission details ...
CaseIH Magnum 355 Rowtrac Power
Engine (gross)355 hp
264.7 kW
Engine (max)390 hp
290.8 kW
Engine (boost)410 hp
305.7 kW
PTO (claimed)303 hp
225.9 kW
Mechanical
Drivehalf-track
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Cab standard with air-conditioning.
Photos
No photos of the CaseIH Magnum 355 Rowtrac are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typepressure flow compensating
Valves5 or 6
Pump flow59 gpm
223.3 lpm
 86 gpmOptOptional
325.5 lpm
Tractor hitch
Rear TypeIV/III
Rear lift19900 lbs
9026 kg
Front lift9426 lbs
4275 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
 540/1000 (1.375)OptOptional
Front PTOindependent
Front PTO Type1000 (1.375)
 1000 (1.75)
Dimensions & Tires
Wheelbase124 inches
314 cm
Weight36000 lbs
16329 kg
Front tire420/85R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps240
Batteries2
Battery volts12
References
Magnum 355 Rowtrac references literature
Magnum published in 2025, by CaseIH
