Tractors > Massey Ferguson > 5M.145

Massey Ferguson 5M.145



Massey Ferguson 5M.145 tractor photo
2025 -
5M Series
Utility tractor
Series map:
5M.135
5M.145
130.0hp
140.0hp
Production
ManufacturerMassey Ferguson (a part of AGCO)
Utility tractor
Massey Ferguson 5M.145 Engine
AGCO Power 4.4L 4-cyl diesel
Fuel tank52.3 gal
198.0 L
Exhaust fluid (DEF)4.8 gal
18.2 L
Engine details ...
Massey Ferguson 5M.145 Transmission
16-speed four-speed power shift
Transmission details ...
Massey Ferguson 5M.145 Power
Engine140 hp
104.4 kW
Engine (max)145 hp
108.1 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic
 pneumatic OptOptional
Cab standard with available air-conditioning.
Photos
No photos of the Massey Ferguson 5M.145 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2901 psi
200.0 bar
Valves2 or 3
Pump flow15.3 gpm
57.9 lpm
 26.4 gpmOptOptional
99.9 lpm
Steering flow8.5 gpm
32.2 lpm
Tractor hitch
Rear TypeIII
Rear lift11464 lbs
5200 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
Engine RPM540@2000
 540E@1550
 1000@2000
Dimensions & Tires
Wheelbase103.2 inches
262 cm
Weight9921 lbs
4500 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
5M.145 references literature
MF 5M - Affordable Efficiency published in 2024, by Massey Ferguson
