Tractors > Massey Ferguson > 5713M

Massey Ferguson 5713M



Massey Ferguson 5713M tractor photo
2020 - 2024
5700 M Series
Utility tractor
Series map:
5712M
5713M
120.0hp
130.0hp
Production
ManufacturerMassey Ferguson (a part of AGCO)
Utility tractor
Variants
5713Mbasic
5713Sdeluxe
Massey Ferguson 5713M Engine
AGCO Power 4.4L 4-cyl diesel
Fuel tank40.4 gal
152.9 L
Exhaust fluid (DEF)4.8 gal
18.2 L
Engine details ...
Massey Ferguson 5713M Transmission
12-speed power shuttle
Transmission details ...
Massey Ferguson 5713M Power
Engine130 hp
96.9 kW
Engine (max)135 hp
100.7 kW
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Cab standard with available air-conditioning.
Photos
No photos of the Massey Ferguson 5713M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2901 psi
200.0 bar
Valves2 or 3
Pump flow15.3 gpm
57.9 lpm
 26.4 gpmOptOptional
99.9 lpm
Steering flow8.7 gpm
32.9 lpm
Tractor hitch
Rear TypeIII
Rear lift11464 lbs
5200 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
Engine RPM540@2000
 540E@1550
 1000@2000
Dimensions & Tires
Wheelbase98.4 inches
249 cm
Weight9326 lbs
4230 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
5713M references literature
MF 5700 M published in 2021, by Massey Ferguson
