Claas Nexos 230
|
|
| Production | |
| Distributor | Claas |
| Manufacturer | Carraro |
| Orchard/Vineyard tractor | |
| Built in Rovigo, Italy | |
| Claas Nexos 230 Engine | |
| FPT 3.2L 4-cyl diesel | |
| Fuel tank | 19.8 gal 74.9 L |
 Engine details ... | |
| Claas Nexos 230 Transmissions | |
| 12-speed mechanical shuttle | |
| 24-speed mechanical shuttle | |
| 24-speed two-speed power shift | |
| 24-speed power shuttle | |
 Transmission details ... |
| Claas Nexos 230 Power | |
| Engine (gross) | 88 hp 65.6 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Wet disc brakes | |
| Trailer brakes | hydraulic |
| Two-post folding ROPS. Cab available with heat. Optional air-conditioning. | |
| Photos | |
| No photos of the Claas Nexos 230 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2756 psi 190.0 bar |
| Valves | 2 to 4 |
| Pump flow | 15.6 gpm 59.0 lpm |
| 22.5 gpmOptOptional 85.2 lpm | |
| Steering flow | 6.9 gpm 26.1 lpm |
| Tractor hitch | |
| Rear Type | II |
| FB Rear lift (at ends) | 3814 lbs 1730 kg |
| VE Rear lift (at ends) | 3814 lbs 1730 kg |
| F Rear lift (at ends) | 4762 lbs 2160 kg |
| VL Rear lift (at ends) | 4762 lbs 2160 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| F Wheelbase | 81.7 inches 207 cm |
| FB Wheelbase | 81.7 inches 207 cm |
| VL Wheelbase | 82.6 inches 209 cm |
| VE Wheelbase | 82.6 inches 209 cm |
| Weight | 5721 to 6900 pounds |
| Front tire | 320/70R20 |
| F Rear tire | 14.9R28 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Nexos published in 2019, by Claas |
