Tractors > John Deere > 6M 250

John Deere 6M 250



No photo available
2024 -
6M Series
Utility tractor
Series map:
6M 230
6M 250
266.6hp
246.8hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
Original price was $328,766 in 2025
John Deere 6M 250 Engine
John Deere 6.8L 6-cyl diesel
Fuel tank111 gal
420.1 L
Exhaust fluid (DEF)6.2 gal
23.5 L
Engine details ...
John Deere 6M 250 Transmission
infinitely variable transmission
Transmission details ...
John Deere 6M 250 Power
Engine (gross)246.8 hp
184.0 kW
Engine (max)270.9 hp
202.0 kW
PTO (claimed)195 hp
145.4 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Differential lockelectro-hydraulic
Power steering
Cab standard with air-conditioning. JDLink
Photos
No photos of the John Deere 6M 250 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Rear valves0 to 3
Mid valves2 to 4
Pump flow41 gpm
155.2 lpm
 51 gpmOptOptional
193.0 lpm
Tractor hitch
Rear TypeIII/IIIN
Rear lift (at 24"/610mm)12996 lbs
5894 kg
 14593 lbsOptOptional
6619 kg
Front HitchIIIN
Front lift9692 lbs
4396 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Engine RPM540@1960
 1000@1960
Front PTOindependent OptOptional
Clutchelectro-hydraulic wet disc
Front PTO Type1000 (1.375)
Engine RPM1000@1967
Dimensions & Tires
Wheelbase114.2 inches
290 cm
Weight18739 to 21164 pounds
Front tire420/85R30
Rear tire520/85R42
Full dimensions and tires ...
John Deere 6M 250 attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps250
Battery volts12
References
6M 250 references literature
6M Tractors published in 2024, by John Deere
