Tractors > John Deere > 6M 220

John Deere 6M 220



No photo available
2024 -
6M Series
Utility tractor
Series map:
6M 200
6M 220
6M 240
197.1hp
217.3hp
237.4hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
Original price was $271,426 in 2025
John Deere 6M 220 Engine
John Deere 6.8L 6-cyl diesel
Fuel tank85.9 gal
325.1 L
Exhaust fluid (DEF)6.2 gal
23.5 L
Engine details ...
John Deere 6M 220 Transmissions
20-speed four-speed power shift
infinitely variable transmission
Transmission details ...
John Deere 6M 220 Power
Engine (gross)217.3 hp
162.0 kW
Engine (max)238.7 hp
178.0 kW
PTO (claimed)177 hp
132.0 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Differential lockelectro-hydraulic
Power steering
Cab standard with air-conditioning. JDLink
Photos
No photos of the John Deere 6M 220 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Rear valves0 to 3
Mid valves2 to 4
Pump flow30 gpm
113.6 lpm
 41 gpmOptOptional
155.2 lpm
Tractor hitch
Rear TypeIII/IIIN
Rear lift (at 24"/610mm)10132 lbs
4595 kg
 11346 lbsOptOptional
5146 kg
Front HitchIIIN
Front lift7269 lbs
3297 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Engine RPM540@1960
 1000@1960
Front PTOindependent OptOptional
Clutchelectro-hydraulic wet disc
Front PTO Type1000 (1.375)
Engine RPM1000@1969
Dimensions & Tires
Wheelbase110.2 inches
279 cm
Weight18739 to 19180 pounds
Front tire420/85R30
Rear tire480/80R46
Full dimensions and tires ...
John Deere 6M 220 attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps125
 250 OptOptional
Battery volts12
References
6M 220 references literature
6M Tractors published in 2024, by John Deere
