Tractors > John Deere > 6M 155

John Deere 6M 155



No photo available
2024 -
6M Series
Utility tractor
Series map:
6M 145
6M 155
6M 165
143.5hp
152.9hp
162.3hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
Original price was $213,462 in 2025
Variants
6MH 155high-crop
John Deere 6M 155 Engine
John Deere 6.8L 6-cyl diesel
Fuel tank75.3 gal
285.0 L
Exhaust fluid (DEF)6.2 gal
23.5 L
Engine details ...
John Deere 6M 155 Transmissions
20-speed four-speed power shift
infinitely variable transmission
Transmission details ...
John Deere 6M 155 Power
Engine (gross)152.9 hp
114.0 kW
Engine (max)167.6 hp
125.0 kW
PTO (claimed)120 hp
89.5 kW
Mechanical
Two- or four-wheel drive
Final drivesplanetary
Differential lockelectro-hydraulic
Power steering
Cab standard with air-conditioning. JDLink
Photos
No photos of the John Deere 6M 155 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Rear valves0 to 3
Mid valves2 to 4
Pump flow30 gpm
113.6 lpm
 41 gpmOptOptional
155.2 lpm
Tractor hitch
Rear TypeIII/IIIN
Rear lift (at 24"/610mm)7709 lbs
3496 kg
 8700 lbsOptOptional
3946 kg
Front HitchIIIN
Front lift7269 lbs
3297 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Engine RPM540@1997
 1000@2010
Front PTOindependent OptOptional
Clutchelectro-hydraulic wet disc
Front PTO Type1000 (1.375)
Engine RPM1000@1969
Dimensions & Tires
Wheelbase108.8 inches
276 cm
Weight17196 to 17637 pounds
Front tire420/85R28
Rear tire480/80R42
Full dimensions and tires ...
John Deere 6M 155 attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps125
 250 OptOptional
Battery volts12
References
6M 155 references literature
6M Tractors published in 2024, by John Deere
