Massey Ferguson 1M.35
|
|
| Production | |
| Manufacturer | Massey Ferguson (a part of AGCO) |
| Compact Utility tractor | |
| Massey Ferguson 1M.35 Engine | |
| Iseki 1.8L 3-cyl diesel | |
| Fuel tank | 10.6 gal 40.1 L |
 Engine details ... | |
| Massey Ferguson 1M.35 Transmissions | |
| 12-speed power shuttle | |
| hydrostatic | |
 Transmission details ... |
| Massey Ferguson 1M.35 Power | |
| Engine | 36.2 hp 27.0 kW |
| Gear PTO (claimed) | 27.5 hp 20.5 kW |
| Hydro PTO (claimed) | 25.7 hp 19.2 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Two-post folding ROPS. Cab optional with air-conditioning. |
| Photos | |
| No photos of the Massey Ferguson 1M.35 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pump flow | 12.6 gpm 47.7 lpm |
| Steering flow | 7 gpm 26.5 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at ends) | 2800 lbs 1270 kg |
| Rear lift (at 24"/610mm) | 2535 lbs 1149 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Weight | 3472 to 3858 pounds |
 Full dimensions and tires ... | |
| Massey Ferguson 1M.35 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| 1M Series published in 2025, by Massey Ferguson | |
| Compact and Utility Equipment Lineup published in 2025, by Massey Ferguson |
