Production | |
Manufacturer | Massey Ferguson (a part of AGCO) |
Compact Utility tractor |
Massey Ferguson 1M.35 Engine | |
Iseki 1.8L 3-cyl diesel | |
Fuel tank | 10.6 gal 40.1 L |
![]() |
Massey Ferguson 1M.35 Transmissions | |
12-speed power shuttle | |
hydrostatic | |
![]() |
Massey Ferguson 1M.35 Power | |
Engine | 36.2 hp 27.0 kW |
Gear PTO (claimed) | 27.5 hp 20.5 kW |
Hydro PTO (claimed) | 25.7 hp 19.2 kW |
Mechanical | |
Four-wheel drive | |
Power steering | |
Two-post folding ROPS. Cab optional with air-conditioning. |
Photos | |
No photos of the Massey Ferguson 1M.35 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics | |
Type | open center |
Pump flow | 12.6 gpm 47.7 lpm |
Steering flow | 7 gpm 26.5 lpm |
Tractor hitch | |
Rear Type | I |
Rear lift (at ends) | 2800 lbs 1270 kg |
Rear lift (at 24"/610mm) | 2535 lbs 1149 kg |
Power Take-off (PTO) | |
Rear PTO | independent |
Rear PTO Type | 540 (1.375) |
Dimensions & Tires | |
Weight | 3472 to 3858 pounds |
![]() |
Massey Ferguson 1M.35 attachments | |
front-end loader | |
backhoe | |
![]() |
Electrical | |
Ground | negative |
Battery volts | 12 |
References | |
![]() | |
1M Series published in 2025, by Massey Ferguson | |
Compact and Utility Equipment Lineup published in 2025, by Massey Ferguson |
