Mahindra 4540
| | 2024 - |
| Compact Utility tractor |
|
Series map:
4540
4550
41.0hp
48.0hp
| Production |
| Manufacturer | Mahindra
|
| Compact Utility tractor |
| Mahindra 4540 Power |
| Engine | 41 hp
30.6 kW
|
| PTO (claimed) | 31 hp
23.1 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Dry disc brakes |
| Two-post folding ROPS. |
| Photos |
| No photos of the Mahindra 4540 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Rear valves | 1 OptOptional
|
| Pump flow | 8.7 gpm
32.9 lpm
|
| Steering flow | 5.8 gpm
22.0 lpm
|
| Tractor hitch |
| Rear Type | II/I
|
| Rear lift | 3525 lbs
1598 kg
|
| Power Take-off (PTO) |
| Rear PTO | live
|
| Clutch | 540:2058
|
| Rear PTO Type | 540 (1.375)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 45
|
| Battery volts | 12
|
| References |
 |
| 4500 Series published in 2024, by Mahindra |
