Mahindra 1126
| | 2024 - |
| 1100 Series | | Sub-Compact Utility tractor |
|
Series map:
1123
1126
22.9hp
25.3hp
| Production |
| Manufacturer | Mahindra
|
| Sub-Compact Utility tractor |
| Mahindra 1126 Power |
| Engine | 25.3 hp
18.9 kW
|
| PTO (claimed) | 19.2 hp
14.3 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Two-post folding ROPS. Cab optional with heater. |
| Photos |
| No photos of the Mahindra 1126 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Rear valves | 2 OptOptional
|
| Pump flow | 7.6 gpm
28.8 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| Rear lift (at 24"/610mm) | 771 lbs
349 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | wet disc
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2837
|
| Mid PTO | independent OptOptional
|
| Engine RPM | 2500@2837
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 55
|
| Battery CCA | 650
|
| Battery volts | 12
|
| References |
 |
| New 1100 Series published in 2024, by Mahindra |
| Operator's Manual 1120/1123/1126 HST (008032496K91) published in 2024 |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on July 18, 2025 |
