Kioti CK3510SE
|
|
| Production | |
| Manufacturer | Kioti (a part of Daedong) |
| Compact Utility tractor | |
| Kioti CK3510SE Engine | |
| Daedong 1.8L 3-cyl diesel | |
| Fuel tank | 9 gal 34.1 L |
 Engine details ... | |
| Kioti CK3510SE Transmissions | |
| 12-speed synchro shuttle | |
| hydrostatic | |
 Transmission details ... |
| Kioti CK3510SE Power | |
| Engine (gross) | 34.9 hp 26.0 kW |
| Gear PTO (claimed) | 30.9 hp 23.0 kW |
| Hydro PTO (claimed) | 28.9 hp 21.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Two-post folding ROPS. | |
| Photos | |
| No photos of the Kioti CK3510SE are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 2 or 3 |
| Pump flow | 11.3 gpm 42.8 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at 24"/610mm) | 1631 lbs 739 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | independent OptOptional |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 65.7 inches 166 cm |
| Weight | 2906 to 3397 pounds |
| Front tire | 7-16 |
| Rear tire | 11.2-24 |
 Full dimensions and tires ... | |
| Kioti CK3510SE attachments | |
| snowblower | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| CK10SE Series published in 2021, by Kioti |
