Kubota L1511
|
|
| Production | |
| Manufacturer | Kubota |
| Compact Utility tractor | |
| Built in Japan | |
| Kubota L1511 Engine | |
| Kubota 0.7L 2-cyl diesel | |
| Fuel tank | 5.8 gal 22.0 L |
 Engine details ... | |
| Kubota L1511 Transmission | |
| hydrostatic | |
 Transmission details ... |
| Kubota L1511 Power | |
| Engine | 14.8 hp 11.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Manual steering | |
| Open operator station. |
| Photos | |
| No photos of the Kubota L1511 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | JIS1 |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2430 |
| 908@2800 | |
| 1252@2800 | |
| Dimensions & Tires | |
| Wheelbase | 54.5 inches 138 cm |
| Weight | 1576 to 1753 pounds |
| Front tire | 4.00-12 |
| 2WD Rear tire | 8.3/8-22 |
 Full dimensions and tires ... | |
| L1511 Serial Number Location | |
 | |
| Serial number plate on the left side of the L1511 tractor frame, just ahead of the clutch pedal. |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Parts Manual (Z)L1501, 1801, 2201 (07909-14760) published in 1979 |
