Gray Tractor 18-36
| | 1918 - 1921 |
| Standard-tread tractor |
|
Series map:
18-36
36.0hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | Gray Tractor
|
| Standard-tread tractor |
| Built in Minneapolis, Minnesota, USA |
| Gray Tractor 18-36 Power |
| Drawbar (claimed) | 18 hp
13.4 kW
|
| Belt (claimed) | 36 hp
26.8 kW
|
| Plows | 4
|
| Drawbar (tested) | 19.64 hp
14.6 kW
|
| Belt (tested) | 32.20 hp
24.0 kW
|
 Performance test details ... |
| Mechanical |
| Drive | 3x1 drum drive
|
| Manual steering |
| Open operator station. |
| 18-36 Serial Number Location |
 |
| Serial number plate on the left side of the tractor, on top of the transmission case. |
| Belt Pulley |
| Diameter | 11 inches
27 cm
|
| Width | 8 inches
20 cm
|
| References |
 |
| The Gray Tractor with the Wide Drive Drum published in 1919 |
