Nichols-Shepard 35-70
|
|
| Production | |
| Manufacturer | Nichols-Shepard |
| Standard-tread tractor | |
| Built in Battle Creek, Michigan, USA | |
| Nichols-Shepard 35-70 Engine | |
| Nichols & Shepard 39.7L 2-cyl kerosene | |
| Fuel tank | 40 gal 151.4 L |
| Aux. fuel | 6 gal 22.7 L |
 Engine details ... | |
| Nichols-Shepard 35-70 Power | |
| Drawbar (claimed) | 70 hp 52.2 kW |
| Belt (claimed) | 35 hp 26.1 kW |
| Plows | 10 (14-inch) |
| Mechanical | |
| Two-wheel drive | |
| Final drives | bull gear |
| Manual steering | |
| Open operator station. | |
| Photos | |
| No photos of the Nichols-Shepard 35-70 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Dimensions & Tires | |
| Weight | 30000 lbs 13608 kg |
| Front tire | 48x12 |
| Rear tire | 73x32 |
 Full dimensions and tires ... | |
| Belt Pulley | |
| Diameter | 30 inches 76 cm |
| Width | 12 inches 30 cm |
| RPM | 375 |
| References | |
 | |
| Threshing Machinery published in 1916, by Nichols-Shepard | |
| Threshing Machinery Makes Good published in 1918, by Nichols-Shepard | |
| Red River Special Line published in 1922, by Nichols-Shepard | |
| Threshing Machinery Exclusively. published in 1924, by Nichols-Shepard | |
| Oil-Gas Tractors published by Nichols-Shepard |
