CaseIH Steiger 475 Rowtrac

No photo available
2024 -
Steiger Rowtrac Series
Articulated Crawler tractor
Series map:
Steiger 425 Rowtrac
Steiger 475 Rowtrac
Steiger 525 Rowtrac
ManufacturerCaseIH (a part of CNH)
Articulated Crawler tractor
Built in Fargo, North Dakota, USA
CaseIH Steiger 475 Rowtrac Engine
FPT 12.9L 6-cyl diesel
Fuel tank340 gal
1286.9 L
Exhaust fluid (DEF)42 gal
159.0 L
Engine details ...
CaseIH Steiger 475 Rowtrac Transmissions
17-speed full power shift
continuously-variable transmission
Transmission details ...
CaseIH Steiger 475 Rowtrac Power
Engine (gross)468.5 hp
349.4 kW
Engine (max)514.9 hp
384.0 kW
PTO (claimed)455.7 hp
339.8 kW
Drivearticulated crawler
Final drivesplanetary
Articulated power steering
Cab standard with air-conditioning.
No photos of the CaseIH Steiger 475 Rowtrac are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Typeclosed center
Valves4 to 8
Pump flow42 gpm
159.0 lpm
 57 gpmOptOptional
215.7 lpm
 113 gpmOptOptional
427.7 lpm
SCV flow35 gpm
132.5 lpm
Tractor hitch
Rear TypeIVN/III
Rear lift (at 24"/610mm)21903 lbs
9935 kg
DrawbarCat 4
 Cat 5 OptOptional
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Dimensions & Tracks
Wheelbase160 inches
406 cm
Weight52200 lbs
23677 kg
18-inch tracks
Full dimensions and tracks ...
Charging systemalternator
Charging amps240
 330 OptOptional
Battery CCA950
Battery volts12
Steiger 475 Rowtrac references literature
TAFS Connect Steiger published in 2024, by New Holland
