Tractors > CaseIH > Steiger 645

CaseIH Steiger 645



CaseIH Steiger 645 tractor photo
2024 -
Steiger 4WD Series
Four-wheel Drive (4WD) tractor
Series map:
Steiger 595
Steiger 645
586.9hp
636.2hp
Production
ManufacturerCaseIH (a part of CNH)
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
Original price was $854,174 in 2026
Variants
T9.700similar New Holland model
CaseIH Steiger 645 Engine
FPT 12.9L 6-cyl diesel
Fuel tank455 gal
1722.2 L
Exhaust fluid (DEF)66 gal
249.8 L
Engine details ...
CaseIH Steiger 645 Transmission
17-speed full power shift
Transmission details ...
CaseIH Steiger 645 Power
Engine (gross)636.2 hp
474.4 kW
Engine (max)689.4 hp
514.1 kW
PTO (claimed)529.6 hp
394.9 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Differential lockautomatic front and rear
Articulated power steering
Cab standard with air-conditioning.
Photos
No photos of the CaseIH Steiger 645 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center
Valves4 to 8
Pump flow42 gpm
159.0 lpm
 57 gpmOptOptional
215.7 lpm
 113 gpmOptOptional
427.7 lpm
SCV flow35 gpm
132.5 lpm
Tractor hitch
Rear TypeIVN
Rear lift (at 24"/610mm)22750 lbs
10319 kg
DrawbarCat 4
 Cat 5 OptOptional
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Dimensions & Tires
Wheelbase154 inches
391 cm
Weight50328 lbs
22828 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps240
 330 OptOptional
Batteries3
Battery CCA950
Battery volts12
References
Steiger 645 references literature
AFS Connect Steiger published in 2024, by CNH Industrial
Steiger published in 2024, by CNH Industrial
