CaseIH Steiger 555
|
|
| Production | |
| Manufacturer | CaseIH (a part of CNH) |
| Four-wheel Drive (4WD) tractor | |
| Built in Fargo, North Dakota, USA | |
| CaseIH Steiger 555 Engine | |
| FPT 12.9L 6-cyl diesel | |
| Fuel tank | 455 gal 1722.2 L |
| Exhaust fluid (DEF) | 66 gal 249.8 L |
 Engine details ... | |
| CaseIH Steiger 555 Transmissions | |
| 17-speed full power shift | |
| continuously-variable transmission | |
 Transmission details ... |
| CaseIH Steiger 555 Power | |
| Engine (gross) | 547.4 hp 408.2 kW |
| Engine (max) | 605.6 hp 451.6 kW |
| PTO (claimed) | 529.6 hp 394.9 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | planetary |
| Differential lock | automatic front and rear |
| Articulated power steering | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the CaseIH Steiger 555 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center |
| Valves | 4 to 8 |
| Pump flow | 42 gpm 159.0 lpm |
| 57 gpmOptOptional 215.7 lpm | |
| 113 gpmOptOptional 427.7 lpm | |
| SCV flow | 35 gpm 132.5 lpm |
| Tractor hitch | |
| Rear Type | IVN |
| Rear lift (at 24"/610mm) | 22750 lbs 10319 kg |
| Drawbar | Cat 4 |
| Cat 5 OptOptional | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 1000 (1.75) |
| Dimensions & Tires | |
| Wheelbase | 154 inches 391 cm |
| Weight | 46340 lbs 21019 kg |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 240 |
| 330 OptOptional | |
| Batteries | 3 |
| Battery CCA | 950 |
| Battery volts | 12 |
| References | |
 | |
| TAFS Connect Steiger published in 2024, by New Holland |
