Tractors > CaseIH > Magnum 400

CaseIH Magnum 400 Tests



CaseIH Magnum 400 tractor photo
2019 -
Magnum Series
Row-Crop tractor
Series map:
Magnum 380
Magnum 400
373.0hp
391.0hp
OCED Tractor Test 2242
Magnum 400 fuel use from test 1202
OCED Tractor Test 2242
Diesel Power shift 4WD
October 4 - 12, 2022
Link: OCED Tractor Test 2242 file
PTO performance
Max power390.64 hp
291.3 kW
Fuel use20.0 gal/hour
75.7 l/hour
Power at rated engine speed350.77 hp
261.6 kW
Fuel use18.3 gal/hour
69.3 l/hour
Power at rated PTO speed385.04 hp
287.1 kW
Fuel use19.7 gal/hour
74.6 l/hour
Drawbar performance
Max power309.80 hp
231.0 kW
Fuel use18.4 gal/hour
69.6 l/hour
Gear 9 used for power test.
Max pull29612 lbs
13432 kg
Gear 6 used for pull test.
