CaseIH Magnum 340



CaseIH Magnum 340 tractor photo
2011 - 2025
Model year
Magnum Series
Row-Crop tractor
Series map:
Magnum 310
Magnum 340
Magnum 380
307.0hp
335.0hp
373.0hp
Production
ManufacturerCaseIH (a part of CNH)
Row-Crop tractor
Built in Racine, Wisconsin, USA
Original price$543,571 (2024 PS )
$555,785 (2024 CVT )
Variants
Magnum 340wheeled
Magnum 380RThalf-track
CaseIH Magnum 340 Engine
FPT 8.7L 6-cyl diesel
PS Fuel tank179 gal
677.5 L
CVT Fuel tank163 gal
617.0 L
Exhaust fluid (DEF)26 gal
98.4 L
Engine details ...
CaseIH Magnum 340 Transmissions
19-speed full power shift
continuously-variable transmission
18-speed full power shift
Transmission details ...
CaseIH Magnum 340 Power
Engine (gross)335 hp
249.8 kW
Engine (max)369 hp
275.2 kW
PTO (claimed)290 hp
216.3 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic rear
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Cab standard with air-conditioning. AFS
Photos
No photos of the CaseIH Magnum 340 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typepressure flow compensating (PFC)
Pressure3046 psi
210.0 bar
Valves5 or 6
Pump flow44 gpm
166.5 lpm
 59 gpmOptOptional
223.3 lpm
 75 gpmOptOptional
283.9 lpm
Tractor hitch
Rear TypeIV/III
Rear lift17500 lbs
7938 kg
Front lift9426 lbs
4275 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type1000 (1.75)
 540/1000 (1.375)OptOptional
Engine RPM540@1592
 1000@1803
Front PTOindependent
Front PTO Type1000 (1.375)
 540 (1.375)
 1000 (1.75)
Engine RPM1000@1804
Dimensions & Tires
PS Wheelbase120 inches
304 cm
CVT Wheelbase122 inches
309 cm
Weight29600 lbs
13426 kg
Front tire420/85R34
Rear tire480/80R50
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps240
Batteries2
Battery volts12
References
Magnum 340 references literature
Magnum AFS Connect published in 2019, by CaseIH
AFS Connect Magnum published in 2021, by CaseIH
