Landini Discovery 65
|
|
Note: the Landini model Discovery 65 is the same as the Valpadana 9565. The following data is from the 9565 listing. |
| Production | |
| Manufacturer | Landini (a part of Argo) |
| Orchard/Vineyard tractor | |
| Landini Discovery 65 Engine | |
| Deutz 2.7L 4-cyl diesel | |
| Fuel tank | 13.2 gal 50.0 L |
 Engine details ... | |
| Landini Discovery 65 Transmission | |
| 36-speed mechanical shuttle | |
 Transmission details ... |
| Landini Discovery 65 Power | |
| Engine | 64.1 hp 47.8 kW |
| Mechanical | |
| Drive | 4x4 4WD |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Mechanical wet disc brakes | |
| Two-post mid-mount folding ROPS or four-post ROPS. Reversible operator station. | |
| Photos | |
| No photos of the Landini Discovery 65 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Valves | 3 |
| Total flow | 13.2 gpm 50.0 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position control |
| Rear lift | 3307 lbs 1500 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Multitrac Wheelbase | 60.2 inches 152 cm |
| Climber Wheelbase | 62 inches 157 cm |
| Weight | 4409 to 4630 pounds |
| Front tire | 320/70-20 |
| Multitrac Rear tire | 320/70-20 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Discovery Multitrac/Climber published in 2001, by Landini |
