Landini 6-160L


Landini 6-160L tractor photo
2014 - 2022
6L Series
Row-Crop tractor
Production
ManufacturerLandini (a part of Argo)
Row-Crop tractor
Variants
X6.470similar McCormick Intl model
Landini 6-160L Engine
FPT 4.5L 4-cyl diesel
Fuel tank71.3 gal
269.9 L
Exhaust fluid (DEF)10 gal
37.9 L
Engine details ...
Landini 6-160L Transmissions
18-speed mechanical shuttle
54-speed three-speed power shift
Transmission details ...
Landini 6-160L Power
Engine (gross)147.5 hp
110.0 kW
Engine (max)160.9 hp
120.0 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Cab standard with air-conditioning.
Photos
No photos of the Landini 6-160L are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow23 gpm
87.1 lpm
SCV flow23 gpm
87.1 lpm
Total flow33 gpm
124.9 lpm
Steering flow10 gpm
37.9 lpm
Tractor hitch
Rear TypeIII/II
Front HitchII OptOptional
Front lift7716 lbs
3499 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Dimensions & Tires
Wheelbase107 inches
271 cm
Weight13530 lbs
6137 kg
Front tire480/65R28
Rear tire650/65R38
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
6-160L references literature
6L Series published in 2015, by Landini
