Claas Arion 630


Claas Arion 630 tractor photo
2007 - 2025
Model year
Arion 600 Series
Row-Crop tractor
Series map:
Arion 620
Arion 630
Arion 640
111.9kw
118.6kw
126.0kw
Production
ManufacturerClaas
Row-Crop tractor
Claas Arion 630 Engine
John Deere 6.8L 6-cyl diesel
Fuel tank87.2 gal
330.1 L
Engine details ...
Claas Arion 630 Power
Engine (net)159 hp
118.6 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Claas Arion 630 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeload sensing
Pressure2900 psi
200.0 bar
Valves2 to 6
Pump flow29.1 gpm
110.1 lpm
Tractor hitch
Rear TypeIII
Rear lift (at 24"/610mm)9259 lbs
4199 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchwet disc
Rear PTO Type540/1000 (1.375)
 1000 (1.75)
Front PTOindependent OptOptional
Front PTO Type1000
Dimensions & Tires
Wheelbase111 inches
281 cm
Weight14484 lbs
6569 kg
Front tire16.9R28
Rear tire20.8R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
Arion 630 references literature
Arion published in 2012, by Claas
