Claas Arion 550

Claas Arion 550 tractor photo
2012 - 2025
Model year
Arion 500 Series
Row-Crop tractor
Series map:
Arion 540
Arion 550
Row-Crop tractor
Claas Arion 550 Engine
John Deere 4.5L 4-cyl diesel
Fuel tank65 gal
246.0 L
Engine details ...
Claas Arion 550 Power
Engine (net)158 hp
117.8 kW
Four-wheel drive
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
No photos of the Claas Arion 550 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Typeload sensing
Pressure2900 psi
200.0 bar
Valves2 to 6
Pump flow29.1 gpm
110.1 lpm
Tractor hitch
Rear TypeIII
Rear lift (at 24"/610mm)9259 lbs
4199 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchwet disc
Rear PTO Type540/1000 (1.375)
 1000 (1.75)
Front PTOindependent OptOptional
Front PTO Type1000
Dimensions & Tires
Wheelbase100.9 inches
256 cm
Weight13272 lbs
6020 kg
Front tire14.9R28
Rear tire18.4R38
Full dimensions and tires ...
Charging systemalternator
Battery volts12
Arion 550 references literature
Arion published in 2012, by Claas
