Kubota L3001
|
|
| Production | |
| Manufacturer | Kubota |
| Compact Utility tractor | |
| Kubota L3001 Engine | |
| Kubota 1.5L 4-cyl diesel | |
| Fuel tank | 9.25 gal 35.0 L |
 Engine details ... | |
| Kubota L3001 Power | |
| Engine (net) | 29.6 hp 22.1 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Open operator station. |
| Photos | |
| No photos of the Kubota L3001 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | JIS1 |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 622@2800 |
| 809@2800 | |
| 1161@2800 | |
| 1400@2800 | |
| Dimensions & Tires | |
| Wheelbase | 69.5 inches 176 cm |
| Weight | 2700 lbs 1224 kg |
| Front tire | 5.50-16 |
| 2WD Rear tire | 12.4/11-28 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| L3001 published in 1976, by Kubota | |
| L3001DT published in 1977, by Kubota |
