Fendt 614 Vario
|
|
| Production | |
| Manufacturer | Fendt (a part of AGCO) |
| Utility tractor | |
| Fendt 614 Vario Engine | |
| AGCO Power 5.0L 4-cyl diesel | |
| Fuel tank | 91.7 gal 347.1 L |
| Exhaust fluid (DEF) | 9.5 gal 36.0 L |
 Engine details ... | |
| Fendt 614 Vario Transmission | |
| continuously-variable transmission | |
 Transmission details ... |
| Fendt 614 Vario Power | |
| Engine (gross) | 149 hp 111.1 kW |
| Engine (boost) | 164 hp 122.3 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | planetary |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| pneumatic OptOptional | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Fendt 614 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | load-sensing |
| Rear valves | 5 OptOptional |
| Mid valves | 3 OptOptional |
| Front valves | 2 OptOptional |
| Pump flow | 40.2 gpm 152.2 lpm |
| 54.2 gpmOptOptional 205.1 lpm | |
| Tractor hitch | |
| Rear Type | III/II |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 107.1 inches 272 cm |
| Weight | 16799 lbs 7620 kg |
| Front tire | 540/65R28 |
| Rear tire | 650/65R38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 220 |
| Charging volts | 14 |
| Battery volts | 12 |
| Battery AH | 180 |
| References | |
 | |
| 600 Vario published in 2025, by Fendt |
