Kioti CX2510
|
|
| Production | |
| Manufacturer | Kioti (a part of Daedong) |
| Compact Utility tractor | |
| Kioti CX2510 Engine | |
| Daedong 1.6L 3-cyl 3A165LWH | |
 Engine details ... |
| Kioti CX2510 Transmissions | |
| 6-speed gear | |
| hydrostatic | |
 Transmission details ... |
| Kioti CX2510 Power | |
| Engine (gross) | 24.5 hp 18.3 kW |
| Gear PTO (claimed) | 19.3 hp 14.4 kW |
| Hydro PTO (claimed) | 18.8 hp 14.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. Cab optional with air-conditioning. | |
| Photos | |
| No photos of the Kioti CX2510 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 6.6 gal 25.0 L |
| Steering | 4.4 qts 4.2 L |
| Hydraulics | |
| Type | open center |
| Rear valves | 1 OptOptional |
| Pump flow | 6.9 gpm 26.1 lpm |
| Total flow | 11.3 gpm 42.8 lpm |
| Steering cap. | 4.4 qts 4.2 L |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at 24"/610mm) | 1203 lbs 545 kg |
| Power Take-off (PTO) | |
| Gear Rear PTO | transmission |
| Hydro Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 52.8 inches 134 cm |
| Weight | 2308 to 2804 pounds |
| Front tire | 7.0-12 |
| Rear tire | 11.2-16 |
 Full dimensions and tires ... | |
| Kioti CX2510 attachments | |
| 60" mid-mount mower deck | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| CX Series 25 HP published in 2021, by Kitoi |
