CaseIH Farmall 25SC
|
|
| Production | |
| Distributor | CaseIH (a part of CNH) |
| Manufacturer | LS |
| Sub-Compact Utility tractor | |
| Built in South Korea | |
| Variants | |
| Workmaster 25S | similar New Holland model |
| CaseIH Farmall 25SC Engine | |
| Yanmar 1.3L 3-cyl diesel | |
| Fuel tank | 6.6 gal 25.0 L |
 Engine details ... | |
| CaseIH Farmall 25SC Power | |
| Engine (gross) | 24.7 hp 18.4 kW |
| PTO (claimed) | 17.2 hp 12.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Two-post folding ROPS. Cab optional. | |
| Photos | |
| No photos of the CaseIH Farmall 25SC are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 1 OptOptional |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at ends) | 991 lbs 449 kg |
| Rear lift (at 24"/610mm) | 728 lbs 330 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | independent |
| Mid PTO Type | 2500 |
| Dimensions & Tires | |
| Wheelbase | 56 inches 142 cm |
| Weight | 1444 to 1884 pounds |
 Full dimensions and tires ... | |
| CaseIH Farmall 25SC attachments | |
| front-end loader | |
 Attachment details ... |
| Farmall 25SC Serial Numbers | |
| Location: | Serial number plate on the left side of the frame, above the front axle. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 40 |
| Battery volts | 12 |
| References | |
 | |
| Farmall Subcompact 25SC Specifications published in 2023, by CaseIH |
