Yanmar SA325
|
|
| Production | |
| Manufacturer | Yanmar |
| Compact Utility tractor | |
| Yanmar SA325 Engine | |
| Yanmar 1.3L 3-cyl diesel | |
| Fuel tank | 6.1 gal 23.1 L |
 Engine details ... | |
| Yanmar SA325 Transmission | |
| hydrostatic | |
 Transmission details ... |
| Yanmar SA325 Power | |
| Engine (gross) | 23.9 hp 17.8 kW |
| Engine (net) | 21.7 hp 16.2 kW |
| PTO (claimed) | 18.1 hp 13.5 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. | |
| Photos | |
| No photos of the Yanmar SA325 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2429 psi 167.5 bar |
| Pump flow | 4.3 gpm 16.3 lpm |
| Steering flow | 3.7 gpm 14.0 lpm |
| Tractor hitch | |
| Rear Type | I (Limited) |
| Control | position control |
| Rear lift (at 24"/610mm) | 1209 lbs 548 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 554@3200 |
| Mid PTO | independent |
| Mid PTO Type | 16/32 15T |
| Engine RPM | 2057@3200 |
| Dimensions & Tires | |
| Wheelbase | 63 inches 160 cm |
| Weight | 1715 lbs 777 kg |
 Full dimensions and tires ... | |
| Yanmar SA325 attachments | |
| 60" mid-mount mower deck | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 40 |
| Battery CCA | 540 |
| Battery volts | 12 |
| References | |
 | |
| SA223/325/425 published in 2022, by Yanmar | |
| 325 Multi-Purpose Compact Tractor published in 2022, by Yanmar* | |
| *Publication contains known errors. |
