Shibaura SP2500
|
|
| Production | |
| Manufacturer | Shibaura |
| Compact Utility tractor | |
| Shibaura SP2500 Engine | |
| Shibaura 1.3L 3-cyl diesel | |
| Fuel tank | 7.1 gal 26.9 L |
 Engine details ... | |
| Shibaura SP2500 Transmission | |
| 12-speed synchromesh | |
 Transmission details ... |
| Shibaura SP2500 Power | |
| Engine | 24.7 hp 18.4 kW |
| Mechanical | |
| Two-wheel drive | |
| Differential lock | mechanical rear |
| Manual steering | |
| Mechanical drum brakes | |
| Open operator station. | |
| Photos | |
| No photos of the Shibaura SP2500 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift | 2976 lbs 1349 kg |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 559@2600 |
| 778@2600 | |
| 1242@2600 | |
| Dimensions & Tires | |
| Wheelbase | 58.3 inches 148 cm |
| Weight | 1894 lbs 859 kg |
| Front tire | 4.00-15 |
| Rear tire | 9.5-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| Battery AH | 70 |
| References | |
 | |
| SP Series published by Shibaura | |
| SP 2500 - SP 2540 published by Shibaura-Paget |
