Lamborghini R8.230

Lamborghini R8.230 tractor photo
2006 - 2012
R8 Series
Row-Crop tractor

Note: the Lamborghini model R8.230 is the same as the SAME Diamond. The following data is from the Diamond listing.
ManufacturerLamborghini (a part of SAME)
Row-Crop tractor
Lamborghini R8.230 Engine
Deutz 7.1L 6-cyl diesel
Fuel tank95.1 gal
360.0 L
 145.3 galOptOptional
550.0 L
Engine details ...
Lamborghini R8.230 Power
Engine (gross)239 hp
178.2 kW
Engine (max)247 hp
184.2 kW
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Trailer brakespneumatic
Cab standard with air-conditioning.
No photos of the Lamborghini R8.230 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Typeload sensing
Pump flow31.7 gpm
120.0 lpm
Tractor hitch
Rear lift23149 lbs
10500 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear RPM540E/1000
Engine RPM540E@1630
Front PTOindependent
Clutchelectro-hydraulic wet disc
Front RPM1000
Dimensions & Tires
Wheelbase121.6 inches
308 cm
Weight18541 lbs
8410 kg
Front tire600/65R38
Rear tire710/70R42
Full dimensions and tires ...
R8.230 references literature
R8 230-270 published in 200, by Lamborghini
