John Deere 6R 250
|
|
| Production | |
| Manufacturer | John Deere |
| Utility tractor | |
| Built in Mannheim, Baden-Württemberg, Germany | |
| Original price was $360,359 in 2023 | |
| John Deere 6R 250 Engine | |
| John Deere 6.8L 6-cyl diesel | |
| Fuel tank | 108.3 gal 409.9 L |
| 124.2 gal 470.1 L | |
| Exhaust fluid (DEF) | 6.6 gal 25.0 L |
 Engine details ... | |
| John Deere 6R 250 Transmission | |
| continuously-variable transmission | |
 Transmission details ... |
| John Deere 6R 250 Power | |
| Engine (gross) | 246.8 hp 184.0 kW |
| Engine (max) | 270.9 hp 202.0 kW |
| PTO (claimed) | 229 hp 170.8 kW |
| 241 hp (IPM Boost) 179.7 kW | |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | electro-hydraulic rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic Opt |
| pneumatic Opt | |
| Cab standard with air-conditioning. | |
| Photos | |
 | |
 John Deere 6R 250 photos... | |
| Hydraulics | |
| Type | closed-center PFC |
| Pressure | 2970 psi 204.8 bar |
| Pump flow | 42.3 gpm 160.1 lpm |
| 51.5 gpm 194.9 lpm | |
| SCV flow | 30.6 gpm 115.8 lpm |
| Tractor hitch | |
| Rear Type | III/IIIN |
| Control | electro-hydraulic draft sensing |
| Rear lift (at 24"/610mm) | 15430 lbs 6999 kg |
| Front Hitch | IIIN |
| Front lift (at ends) | 9700 lbs 4399 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 (1.375) |
| 1000 (1.75) | |
| Engine RPM | 540@1950 |
| 540E@1721 | |
| 1000@1950 | |
| 1000E@1659 | |
| Front PTO | independent |
| Front PTO Type | 1000 |
| Engine RPM | 1000@1965 |
| Dimensions & Tires | |
| Wheelbase | 114 inches 289 cm |
| Weight | 21270 lbs 9648 kg |
| Front tire | 420/85R30 |
| Rear tire | 520/85R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 250 |
| Batteries | 2 |
| Battery volts | 12 |
| Battery AH | 95 |
| References | |
 | |
| 6R Utility Tractors published in 2021, by John Deere | |
| Operator's Manual 6R 230 and 6R 250 (OMAL234787) published in 2021 |
