New Holland Workmaster 120
| | 2019 - |
| Workmaster Series | | Utility tractor |
|
| Production |
| Manufacturer: | New Holland
|
| Type: | Utility tractor
|
| Original price: | $74,686 (2022 ROPS )
|
| Original price: | $91,152 (2022 Cab )
|
| New Holland Workmaster 120 Power |
| Engine (gross): | 120 hp
89.5 kW
|
| PTO (claimed): | 100 hp
74.6 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Final drives: | inboard planetary
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Two-post folding ROPS. Cab optional with air-conditioning.
|
| Transmission: | 12-speed power shuttle
|
 Transmission details ... |
| Hydraulics |
| Type: | open center
|
| Rear valves: | 2 or 3
|
| Pump flow: | 16.9 gpm
64.0 lpm
|
| | 21.6 gpm
81.8 lpm *Optional
|
| Steering flow: | 9.7 gpm
36.7 lpm
|
| Tractor hitch |
| Rear Type: | II/I
|
| Rear lift (at 24"/610mm): | 3200 lbs
1451 kg
|
| | 6200 lbs
2812 kg *Optional
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | electro-hydraulic wet disc
|
| Rear RPM: | 540
|
| | 540/540E*Optionall 540/1000 ((Optional))
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 120
|
| Battery volts: | 12
|
| Page information |
| Last update: | July 1, 2022
|
| Copyright: | Copyright 2022 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2022 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Full dimensions and tires ...
Attachment details ...
