Claas Xerion 4500
|
|
| Production | |
| Manufacturer | Claas |
| Four-wheel Drive (4WD) tractor | |
| Variants | |
| TRAC | wheeled |
| TRAC TS | quad-tracked |
| TRAC VC | rotating cab |
| SADDLE TRAC | forward cab |
| Claas Xerion 4500 Engine | |
| Mercedes-Benz 12.8L 6-cyl diesel | |
 Engine details ... |
| Claas Xerion 4500 Transmission | |
| continuously-variable transmission | |
 Transmission details ... |
| Claas Xerion 4500 Power | |
| Engine (gross) | 480 hp 357.9 kW |
| Engine (max) | 490 hp 365.4 kW |
| Mechanical | |
| Drive | 4x4 4WD |
| Differential lock | electro-hydraulic front and rear |
| Power four-wheel steering | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Claas Xerion 4500 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 195.5 gal 740.0 L |
| Exhaust fluid (DEF) | 23.3 gal 88.2 L |
| Hydraulic system | 31.7 gal 120.0 L |
| Hydraulics | |
| Type | load sensing |
| Capacity | 31.7 gal 120.0 L |
| Pressure | 2900 psi 200.0 bar |
| Rear valves | up to 7 |
| Front valves | up to 3 |
| Pump flow | 51.5 gpm 194.9 lpm |
| 66 gpm*Optional independent third-circuit pump. 249.8 lpm | |
| SCV flow | 27.7 gpm 104.8 lpm |
| Tractor hitch | |
| Rear Type | IVN |
| Control | position and draft control |
| Rear lift | 22481 lbs 10197 kg |
| Front Hitch | IIIN |
| Front lift | 17857 lbs 8099 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 1000 (1.75) |
| 1000 (2.25) | |
| Dimensions & Tires | |
| Wheelbase | 141.7 inches 359 cm |
| Weight | 35935 lbs 16300 kg |
| Front tire | 650/85R38 |
| Rear tire | 650/85R38 |
 Full dimensions and tires ... | |
| References | |
 | |
| Xerion published in 2021, by Claas |
