Claas Talos 230
|
|
| Production | |
| Distributor | Claas |
| Manufacturer | LS |
| Utility tractor | |
| Variants | |
| P7030 | similar LS model |
| Claas Talos 230 Engine | |
| FPT 3.2L 4-cyl diesel | |
| Fuel tank | 26.4 gal 99.9 L |
 Engine details ... | |
| Claas Talos 230 Transmission | |
| 20-speed synchromesh | |
 Transmission details ... |
| Claas Talos 230 Power | |
| Engine | 87.2 hp 65.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic rear |
| Power steering | |
| Two-post folding ROPS. Cab available with air-conditioning. | |
| Photos | |
| No photos of the Claas Talos 230 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Valves | 3 to 6 |
| Pump flow | 11.9 gpm 45.0 lpm |
| Tractor hitch | |
| Rear lift | 6173 lbs 2800 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/540E/1000 |
| Dimensions & Tires | |
| Wheelbase | 86.6 inches 219 cm |
| Weight | 6195 to 6680 pounds |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Talos 200 100 published in 2018, by Claas | |
| Talos 100-200 published by Claas |
