CaseIH Farmall 50A
|
|
| Production | |
| Manufacturer | CaseIH |
| Utility tractor | |
| Built in India | |
| CaseIH Farmall 50A Engine | |
| FPT 2.2L 3-cyl diesel | |
| Fuel tank | 13 gal 49.2 L |
 Engine details ... | |
| CaseIH Farmall 50A Transmission | |
| 8-speed mechanical shuttle | |
 Transmission details ... |
| CaseIH Farmall 50A Power | |
| Engine (gross) | 50 hp 37.3 kW |
| PTO (claimed) | 46 hp 34.3 kW |
| PTO (tested) | 46.39 hp 34.6 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | planetary |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. | |
| Photos | |
| No photos of the CaseIH Farmall 50A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 1 or 2 |
| Mid valves | 0 or 2 |
| Pump flow | 11.9 gpm 45.0 lpm |
| Steering flow | 5.5 gpm 20.8 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift (at 24"/610mm) | 2701 lbs 1225 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2575 |
| 540E@2016 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 96.4 inches 244 cm |
| 4WD Wheelbase | 97.6 inches 247 cm |
| Weight | 4442 to 5060 pounds |
| Front tire | 7.5x16 |
| 2WD Rear tire | 13.6x28 |
 Full dimensions and tires ... | |
| CaseIH Farmall 50A attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 75 |
| Battery volts | 12 |
| References | |
 | |
| Utility Farmall A Series Tractors published in 2016, by CaseIH* | |
| Farmall Utility Series Tractors published in 2021, by CaseIH | |
| *Publication contains known errors. |
