Massey Ferguson 7720S

Massey Ferguson 7720S tractor photo
2018 - 2021
7700S Series
Row-Crop tractor
Series map:
ManufacturerMassey Ferguson (a part of AGCO)
Row-Crop tractor
FactoriesJackson, Minnesota, USA
 Beauvais, France
Massey Ferguson 7720S Engine
AGCO Power 6.6L 6-cyl diesel
Fuel tank114 gal
431.5 L
Exhaust fluid (DEF)10.5 gal
39.7 L
Engine details ...
Massey Ferguson 7720S Transmissions
24-speed six-speed power shift
continuously-variable transmission
Transmission details ...
Massey Ferguson 7720S Power
Engine185 hp
138.0 kW
PTO (claimed)155 hp
115.6 kW
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Cab standard with air-conditioning. Available cab suspension. Massey Ferguson auto-guidance ready
Typeclosed-center load-sensing
Pressure2900 psi
200.0 bar
Rear valves2 to 5
Front valves0 to 3
Pump flow29 gpm
109.8 lpm
 39 gpmOptOptional
147.6 lpm
 50 gpmOptOptional
189.3 lpm
Tractor hitch
Rear TypeIII/II
Controlelectronic draft control
Dyna-6 Rear lift (at ends)13895 lbs
6302 kg
Dyna-VT Rear lift (at ends)16404 lbs
7440 kg
Front lift (at ends)8818 lbs
3999 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Engine RPM540@1890
Front PTOindependent OptOptional
Front PTO Type1000 (1.375)
Dimensions & Tires
Wheelbase117.1 inches
297 cm
Weight16534 lbs
7499 kg
Full dimensions and tires ...
Charging systemalternator
Battery volts12
7720S references literature
7700S Series published in 2020, by Massey Ferguson*
*Publication contains known errors.
