Kubota M5970


No photo available
1984 - 1988
M70 Series
Utility tractor
Series:M5270M5970M6970
Production
Manufacturer:Kubota
Type:Utility tractor
Kubota M5970 Power
Engine:59.5 hp
44.4 kW
PTO (claimed):57.1 hp
42.6 kW
Kubota M5970 Engine
Kubota 3.2L 3-cyl diesel
Fuel tank:18.5 gal
70.0 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Transmission:16-speed
Transmission details ...
Photos
No photos of the Kubota M5970 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow:9.25 gpm
35.0 lpm
Tractor hitch
Rear Type:JISII/I
Rear lift:4189 lbs
1900 kg
Power Take-off (PTO)
Rear RPM:540/1000 (1.375)
Engine RPM:540@2194
1000@2530
Dimensions & Tires
2WD Wheelbase:82.7 inches
210 cm
4WD Wheelbase:83.3 inches
211 cm
Weight:5049 to 5688 pounds
Front tire:6.00-16
2WD Rear tire:12.4-32
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
