Fendt 924 Vario


Fendt 924 Vario tractor photo
2002 - 2013
Model year
900 Vario Series
Row-Crop tractor
Favorit 924 Vario
Series:920 Vario924 Vario926 Vario
Production
Manufacturer:Fendt (a part of AGCO)
Type:Row-Crop tractor
Factory:Marktoberdorf, Germany
Fendt 924 Vario Power
Engine (net):240 hp
179.0 kW
Fendt 924 Vario Engine
MAN 6.9L 6-cyl diesel
Fuel tank:140 gal
529.9 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Cab standard with air-conditioning.
Transmission:continuously-variable transmission
Transmission details ...
Photos
No photos of the Fendt 924 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:load sensing
Pressure:2901 psi
200.0 bar
Pump flow:30.9 gpm
117.0 lpm
Tractor hitch
Rear lift:21468 lbs
9737 kg
Front lift:11240 lbs
5098 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:750/1000
 540/1000
Front PTO:independent*Optional
Front RPM:1000
Dimensions & Tires
Wheelbase:111.8 inches
283 cm
Weight:19401 lbs
8800 kg
Front tire:540/65R34
Rear tire:650/65R42
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
