Fendt 924 Vario
|
|
| Production | |
| Manufacturer | Fendt (a part of AGCO) |
| Row-Crop tractor | |
| Built in Marktoberdorf, Germany | |
| Fendt 924 Vario Engine | |
| MAN 6.9L 6-cyl diesel | |
| Fuel tank | 140 gal 529.9 L |
 Engine details ... | |
| Fendt 924 Vario Transmission | |
| continuously-variable transmission | |
 Transmission details ... |
| Fendt 924 Vario Power | |
| Engine (net) | 240 hp 179.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Cab standard with air-conditioning. |
| Photos | |
| No photos of the Fendt 924 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | load sensing |
| Pressure | 2901 psi 200.0 bar |
| Pump flow | 30.9 gpm 117.0 lpm |
| Tractor hitch | |
| Rear lift | 21468 lbs 9737 kg |
| Front lift | 11240 lbs 5098 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 750/1000 |
| 540/1000 | |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 111.8 inches 283 cm |
| Weight | 19401 lbs 8800 kg |
| Front tire | 540/65R34 |
| Rear tire | 650/65R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| 900 Vario published in 2004, by Fendt |
