Branson 2515
|
|
| Production | |
| Manufacturer | Branson (a part of TYM) |
| Compact Utility tractor | |
| Variants | |
| 2515H | hydrostatic |
| 2515R | shuttle |
| Branson 2515 Engine | |
| Kukje 1.7L 3-cyl diesel | |
| Fuel tank | 7.1 gal 26.9 L |
 Engine details ... | |
| Branson 2515 Transmissions | |
| 12-speed sync shuttle | |
| hydrostatic | |
 Transmission details ... |
| Branson 2515 Power | |
| Engine (gross) | 24 hp 17.9 kW |
| PTO (claimed) | 21 hp 15.7 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. |
| Photos | |
 | |
 Branson 2515 photos... | |
| Hydraulics | |
| Pump flow | 7.5 gpm 28.4 lpm |
| Total flow | 11.5 gpm 43.5 lpm |
| Steering flow | 4 gpm 15.1 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 3306 lbs 1499 kg |
| Rear lift (at 24"/610mm) | 2425 lbs 1099 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | wet disc |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 65.7 inches 166 cm |
| Weight | 2969 to 2989 pounds |
| Front tire | 8-16 |
| Rear tire | 12.4-24 |
 Full dimensions and tires ... | |
| Branson 2515 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 50 |
| Battery volts | 12 |
| References | |
 | |
| 15 Series published in 2020, by Branson |
