Fendt 936 Vario
|
|
| Production | |
| Manufacturer: | Fendt (a part of AGCO) |
| Type: | Row-Crop tractor |
| Factory: | Marktoberdorf, Germany |
| Fendt 936 Vario Power | |
| Engine (gross): | 355 hp 264.7 kW |
| PTO (claimed): | 290 hp 216.3 kW |
| Drawbar (tested): | 275.2 hp 205.2 kW |
| PTO (tested): | 314.6 hp 234.6 kW |
| Fendt 936 Vario Engine | |
| MAN 9.0L 6-cyl diesel | |
 Engine details ... |
| Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Cab: | Cab standard with air-conditioning. |
| Transmission: | continuously-variable transmission |
 Transmission details ... | |
| Photos | |
| No photos of the Fendt 936 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel: | 165.1 gal 624.9 L |
| Exhaust fluid (DEF): | 18.5 gal 70.0 L |
| Hydraulic system: | 23.8 gal 90.1 L |
| Hydraulics | |
| Type: | closed center |
| Capacity: | 23.8 gal 90.1 L |
| Pressure: | 2900 psi 200.0 bar |
| Rear valves: | 6*Optional |
| Front valves: | 2*Optional |
| Pump flow: | 43.6 gpm 165.0 lpm |
| 58.1 gpm 219.9 lpm *Optional | |
| 113.6 gpm 430.0 lpm *Optional. Combination of 220 LPM and 210 LPM pumps. | |
| Tractor hitch | |
| Rear Type: | III/IVN |
| Rear lift: | 27898 lbs 12654 kg |
| Front Hitch: | II*Optional |
| Front lift: | 12553 lbs 5694 kg |
| Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540E/1000 |
| 1000/1000E | |
| Front PTO: | independent*Optional |
| Front RPM: | 1000 |
| Dimensions & Tires | |
| Wheelbase: | 124 inches 314 cm |
| Weight: | 25133 lbs 11400 kg |
| Front tire: | 600/65R34 |
| Rear tire: | 710/75R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 275 |
| Batteries: | 2 |
| Battery volts: | 12 |
