Fendt 930 Vario
|
|
| Production | |
| Manufacturer | Fendt (a part of AGCO) |
| Row-Crop tractor | |
| Built in Marktoberdorf, Germany | |
| Fendt 930 Vario Engine | |
| MAN 9.0L 6-cyl diesel | |
 Engine details ... |
| Fendt 930 Vario Transmission | |
| continuously-variable transmission | |
 Transmission details ... |
| Fendt 930 Vario Power | |
| Engine (gross) | 296 hp 220.7 kW |
| PTO (claimed) | 237 hp 176.7 kW |
| Drawbar (tested) | 222.2 hp 165.7 kW |
| PTO (tested) | 263.9 hp 196.8 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. |
| Photos | |
| No photos of the Fendt 930 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 165.1 gal 624.9 L |
| Exhaust fluid (DEF) | 18.5 gal 70.0 L |
| Hydraulic system | 23.8 gal 90.1 L |
| Hydraulics | |
| Type | closed center |
| Capacity | 23.8 gal 90.1 L |
| Pressure | 2900 psi 200.0 bar |
| Rear valves | 6 OptOptional |
| Front valves | 2 OptOptional |
| Pump flow | 43.6 gpm 165.0 lpm |
| 58.1 gpmOptOptional 219.9 lpm | |
| 113.6 gpm*Optional. Combination of 220 LPM and 210 LPM pumps. 430.0 lpm | |
| Tractor hitch | |
| Rear Type | III/IVN |
| Rear lift | 27898 lbs 12654 kg |
| Front Hitch | II OptOptional |
| Front lift | 12553 lbs 5694 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540E/1000 |
| 1000/1000E | |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 124 inches 314 cm |
| Weight | 24912 lbs 11300 kg |
| Front tire | 650/65R34 |
| Rear tire | 710/70R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 275 |
| Batteries | 2 |
| Battery volts | 12 |
| References | |
 | |
| 900 Vario published in 2019, by Fendt | |
| 900 Series published in 2019, by Fendt |
